LED Sports Lighting

Indoor Linear Sports Court Light 40-60W With Low Glare<19

The Indoor Sports Court Light from the VKS Smash Series is designed to provide comfortable, low-glare illumination for indoor sports facilities. With up to 150 lm/W, high-quality optics and multiple beam distributions, it delivers uniform lighting for padel courts, pickleball courts and indoor tennis venues. Its compact aluminum housing, intelligent control options and long service life make it an ideal solution for modern sports lighting projects.

Beam Angle: Symmetric, Asymmetric
Power: 20W, 80W, 40W, 60W, 30W, 50W
Application: Indoor

Get a Quote

Download

Product Details
Specifications

Product Details

Indoor Linear Sports Court Light Benefits

Reduce glare for improved player comfort and visual performance.
Deliver uniform illumination across the entire playing area.
Lower energy consumption with up to 150 lm/W efficiency.
Minimize maintenance costs with a 100,000-hour service life.
Support flexible lighting layouts with multiple beam distributions.
Easily integrate with intelligent lighting control systems.
Provide a comfortable lighting environment for indoor sports facilities.

Why Choose Our Linear Indoor Sports Court Light

Low UGR optical design for enhanced player comfort.
Three beam distributions optimized for indoor court layouts.
Compact and lightweight fixture for easy installation.
Non-yellowing PC/PMMA lenses for long-term optical performance.
Efficient thermal management for stable operation.
Available in black or white housing to match different indoor venues.

Specifications

Model NO.	VKS-LL0020	VKS-LL0030	VKS-LL0040	VKS-LL0050	VKS-LL0060	VKS-LL0080
Power	20W	30W	40W	50W	60W	80W
Input Voltage	200-240VAC, 50-60Hz
LED Brand	Lumileds
LED Type	SMD 2835/3030/5050
Driver	BOKE
CCT	3000K/4000K/5700K
CRI	>70 (>80,>90 Optional)
SDCM	<5
Power Factor	0.95
Efficacy	130-150lm/W
IP Ratng	IP44
IK Ratng	IK08
Control	On-off / 1-10V / DALI/ DMX512
Surge Protection	10KV (20KV Optional)
Beam Angle	60°/80°/30*70°
Warranty	5 Years
Housing Color	Black/White
Material	Aluminum
Operating Temperature	-30 to +50℃
Life Span	>100,000Hrs @L70
