LED Sports Lighting

G01 Oasis Reflector Design Sports Light

The die-cast housing and mounting bracket are crafted from premium aluminum, ensuring durability and corrosion resistance for outdoor use. <br> The adjustable scale on the bracket allows for precise installation, reducing the need for additional luminaires and saving costs. <br> A professional lighting solution for sports lighting and high mast area lighting can be achieved through excellent reflector optical design. This design effectively addresses issues such as glare, up-light, and spill light while maintaining good uniformity. The result is a friendly and comfortable lighting environment that enhances the overall experience for users.

Beam Angle: Asymmetric
Power: 600W, 1200W, 1800W
Application: Outdoor

Get a Quote

Exceptional Obtrusive Light Control

Advanced reflector technology with clean and sharp cut off light distribution, providing precise and efficient illumination for a variety of applications. This ensures minimal light pollution and maximizes energy savings, making it an ideal choice for environmentally-conscious lighting solutions.
Only light where it needs – no complaints from the neighbors. It’s a considerate way to ensure that everyone is comfortable and happy in their own space.
VKS support narrow, medium & wide reflector optics to fit all your applications. Whether you need a focused beam for precision lighting or a wide beam for broad coverage, VKS has the right optic solution for you. With our versatile range of reflectors, you can achieve the perfect lighting for any environment.

Reliable Structure

The precise rotation of the light module allows for accurate positioning and focusing of the light beam. 1° per unit rotation ensures that the light can be adjusted to the exact angle required for optimal illumination.
Unique bracket design – Auxiliary bracket with track on side bracket, allowing for easy adjustment and customization. This innovative design provides extra support and stability for your equipment, making it ideal for a variety of applications.
Triangle fixing structure with anti-loose feature can provide enhanced stability and security for the light fixture, ensuring it remains securely in place even in windy conditions or with frequent movement. This innovative design helps to prevent any potential loosening or shifting of the light bracket, offering peace of mind for users.

Specifications by Models

Model NO.	VKS-FL0600-G01	VKS-FL1200-G01	VKS-FL1800-G01
Power	600W	1200W	1800W
Input Voltage	200-240VAC, 50-60Hz
LED	Lumileds 5050
Driver	Inventronics/Sosen/Moso
CCT	3000K/4000K/5700K
CRI	>70 (>80,>90 Optional)
SDCM	<5
Power Factor	≧0.95
Efficacy	150lm/W
IP Ratng	IP66
IK Ratng	IK08
Control	On-off / 1-10V / DALI / DMX512
Surge Protection	10KV (20KV Optional)
Beam Angle	A05/A06/A07
Warranty	5 Years
Housing Color	Black/Grey
Material	Aluminum,PC Reflector,Tempered glass
Finish	AkzoNobel Powder Coating
Operating Temperature	-30 to +45°C
Life Span	>100,000Hrs @L70
Net Weight (without driver)(kg)	15	26.5	40
